S.No | Items | Unit | Parameters | Unit |
1. | Machine Model | ------ | JH25-315 | Remark |
| 2. | Main driver driving type | ------ | The crankshaft driving | |
| 3. | Bed body style | ------ | Separated bed body, and strengthening rod hydraulic fastening | |
| 4. | Slide guide way style | ------ | ||
| 5. | Forcing point | Point | 2 | |
| 6. | Capacity | TON | 315 | |
| 7. | Forcing position (Before lower dead position) | mm | 7 | |
| 8. | Stroke | mm | 280 | |
| 9. | Stroke speed (Continuous running style) | SPM | 30-50 times /min | |
| 10. | Max closing working height | mm | 600 | |
| 11. | Die height adjustable value | mm | 120 | |
| 12. | Slider base area(LR×FB) | mm | 2480*900 | |
| 13. | Worktable area(LR×FB) | mm | 3000*1000 | |
| 14. | Main motor(Fixed speed) | Kw | 45Kw | |
| 15. | Machine weight | Ton | 42.5Ton | |
| 16. | Main power | Customized voltage ,such as 380v,415v,220v | ||
1. Hydraulic and pneumatic parts | ||
S.No | Item | Brand |
1 | The combination valve | Japan SMC |
2 | Double Joints solenoid valve | Japan TOYOOKI |
3 | Solenoid valve | Taiwan AIRTAC |
2.Mechanical parts | |||
S.No | Item | Brand | Remark |
1 | Clutch brake | Italy OMPI brand | |
2 | Lining material | Japan NOK | |
3 | Bearing | TIMKEN | |
3.Electric parts | |||
S.No | Item | Brand | Remark |
1 | PLC | Delta | |
2 | Touch screen | Delta | |
3 | Inverter | Delta | |
4 | The circuit breaker | Schneider | |
5 | Contactor | Schneider | |
6 | Relay | Japan OMRON | |
7 | Laser safety | China brand | |
8 | Main motor | China brand | |
9 | Slide adjusting motor | Siemens | |
10 | Approaching switch | Schneider | |
11 | Switch button | Schneider | |
