Rongwin has specialized in metal working machinery and spare parts for 12 years

Home  >  Customized Product  >  Press Brake Machine Warranty  >

machine stainless steel bending machine marketing for bending metal

这里可以自定义设置
machine stainless steel bending machine marketing for bending metal
Nanjing Rongwin Machinery Technology Co.,Ltd. is a distinguished enterprise specialized in production of stainless steel bending machine .
Payment
L/C, T/T
Brand
RONGWIN
参数暂无数据

Add success, do you want to check your shopping cart?

暂无分享
Company Advantages
1. The new type of stainless steel bending machine designed by our engineers is very ingenious and practical. The product can better achieve stress relief
2. Being skilled at solving problems timely, Rongwin's service team has been trusted deeply by customers. Its speed is controllable with input configuration
3. It quality is guaranteed by internationally advanced production equipment and technology. Its surface is well polished to resist rust

Company Features
1. Nanjing Rongwin Machinery Technology Co.,Ltd. is a distinguished enterprise specialized in production of stainless steel bending machine .
2. Our factory is located in a science and technology park where features convenient transportation and beautiful environment. This allows the factory to integrate into the industrial clusters, which helps to cut production costs.
3. Nanjing Rongwin Machinery Technology Co.,Ltd. intends to develop into the world's leading manufacturer. Call!

RONGWIN

PRUODUCT DISCRIPTION



CNC PRESS BRAKE 500T4M

This CNC press brake also called as bending machine is very good accuracy for bending customer’s profile, because we can use international brand linear guide ,ball screw, servo motor to increase the machine accuracy.  We can make the machine be customized design, we have different model for customer to select, like 40Ton, 63Ton, 80tON,100Ton, 125Ton, 160Ton, 125Ton, 160Ton, 200Ton, 250Ton ,300Ton, 400Ton, 500Ton, 600Ton. We also can make the machine according to customer’s bending length,such as 1.3meters ,1.6meters, 2meters, 2.5meters, 3.2meters, 4meters , 5meters, 6meters,if we use Imperial size, the machine length which we can make is

 4 feet,6 feet,8 feet, 10 feet, 12 feet, 20 feet.

Specification of Electro-hydraulic CNC Press Brake with 3 axis with crowing device 500Ton x 4meters (Model No. WF67K-500T/4000   (DELEM DA52S CNC)



No.

Name

Amount

Unit

1

Nominal pressure

5000

KN

2

Workbench length

4000

mm

3

Poles distance

3200

mm

4

Throat depth

450

mm

5

Slipper stroke

300


6

Max. opening height

670

mm

7

Ram speed

Fast descend:80-100

mm/s

Return trip: 60-80

Bending speed : 8

8

Power

37

KW

9

Machine controller

DELEM  DA52 CNC

10

Controlled axes

Y1,Y2,X also crowing device
11

Back gauge range

600

mm

12

Dimension (LxWxH)

4300×2600×4400

mm

13

Weight

 42

T
This is a photo of the main parts of the machine
