• Adopt overall welding structure,after the aging treatment,to ensure the accuracy and reliability of the whole machine.
Hydraulic system adopts Germany Rexroth closed-loop control mode,.The machine is equipped with Roxroth filling valve.and Rexroth synchronization valve block,grating ruler is Italy GIVI pr Germany Heidenhan brand to ensure the synchronization of two cylinders;
• Just input the sheet thickness,width,tensile strength and bending angle,the system will automatically control the pressure and the slider motion .without manual adjustment.
• This machine is equpped with crowning table.as the mechanical compensation point,so the mechanical compensation effect is far greater than the hydraulic compensation,to achieve effective compensation without blind spots and improve the bending accuracy.to ensure the long-term stability.
Back gauge is driven by digital servo motor driver,the full import of precision ball screw drive,and linear guide-oriented,ensure back gauge accuracy and stable repeatability, we also can add more axises as per customer* s request;
• Energy saving .environment friendly design and high efficiency
Pedal switch CNC backg Crowning table Electric cabinet
CNC Control System
One page parameter rapid programming
7"wide-screen 8lor TFT
Maximum 4 axis control(Y1 Y2 and two additional axes)
Table deflection compensation control Mould/matenal/product library
USB peripheral interface
The advanced Y-axis control algorithm can control the closed loop and control the open loop valve Panel mounting structure optional hanging box.
2D graphical touch screen programming mode
3D visualisation in simulating bending steps and production
10" high resolution TFT colour touch screen (wide screen)
Automatic machine tooling
Tool navigator for quick tooling up Quick tool configuration by importing dxf data USB-interface
LAN connection for programming, storage and remote supporting Storage capacity 8 GB Realtime-Monitor and oscilloscope
3D and 2D graphical touch screen programming mode
3D visualization in simulation and production
17"high resolution color TFT
Full windows application suite
Delem modusys compatibility (module scalabilrty and adaptively)
USB, peripheral interfacing
User specific application support within the control's multitasking environment Sensor bending & correction interface Profile-T3D offline software
