CNC V Grooving Machine Vertical style VC 1250x3200

Product Comparison

Rongwin is certified by various qualifications. We have advanced production technology and great production capability. hydraulic metal shear manufacturers has many advantages such as reasonable structure, excellent performance, good quality, and affordable price.Compared with other products in the same category, Rongwin's hydraulic metal shear manufacturers has the following advantages.

Product Details

Rongwin's press brake manufacturer is processed based on the latest technology. It has excellent performances in the following details.press brake manufacturer, manufactured based on high-quality materials and advanced technology, has reasonable structure, excellent performance, stable quality, and long-lasting durability. It is a reliable product which is widely recognized in the market.

Company Advantages
1. The design of groove cutting machine from Nanjing Rongwin Machinery Technology Co.,Ltd. is an overwhelming success.
2. The product can run under extreme conditions. All its components and the electrode leader are inflicted with a certain electric pressure to test its voltage resistance and insulation performance.
3. Whether the motivations are economic, environmental, or personal, the benefits of this product will have something to offer for everyone.

Company Features
1. Nanjing Rongwin Machinery Technology Co.,Ltd. is a professional manufacturer of groove cutting machine .
2. Nanjing Rongwin Machinery Technology Co.,Ltd. has strong technology strength, advanced production technique and complete inspection equipment.
3. Nanjing Rongwin Machinery Technology Co.,Ltd. has a leading industry position and brand. Get an offer! Nanjing Rongwin Machinery Technology Co.,Ltd. has set a goal to become the leader of the v cutting machine industry. Get an offer!

RONGWIN

PRUODUCT DISCRIPTION

RONGWIN Brand auto v grooving machine is widely used in the sheet metal V-groove, U-groove and other irregular groove processing ,which is including stainless steel, aluminum, aluminum plate, copper, iron, plastic, wood, acrylic panels and other special plates.
Particularly, it is can applicable to the V-groove processing of sheet metal before bending .

Max cutting width	1250mm
Max cutting length	3200mm
Max V-cutting thickness	4.0mm(Plate flatness<3.0mm)
Min V-cutting thickness	0.3mm
Back feeding device max moving range	1250mm
Back feeding device moving resolution	0.01mm
Back feeding device max moving speed	800-2000mm/Min
Blade rack max move range(up and down)	50mm
Blade rack move resolution(up and down)	0.01mm
Max moving range of slide rack (left and right)	3500mm
Slide rack max moving speed	30m/min
Straightness error on 4000mm length range	±0.05mm
Distance between V-groove and edge	12mm
Positioning precision	±0.05mm
Blade rack max stroke	100mm
Worktable height	660mm
Machine dimension	5100 x 2400 x 2300（mm）
Machine weight	9000KG

Features:

1 Our machine use structure design,Overall rigidity, small deformation.

2 This machine beam is fixed , has feeding system,worktable levelness is within ±0.03mm.

3 Blade rack move right and left by synchronous belt, V-cutting process is very stable,and the cutting surface is smooth.

CNC system and other configuration

CNC controller	Taiwan HUST-H4-2 axes CNC system
Servo motor	Japan YASKAWA Brand 0.85kw,0.85KW Large inertia servo motors
Inverter	Japan Mitsubishi，Power: 3.7kw
Main axes motor	Germany SEW，Power:3.0kw
Proximity Switch	Germany Turk 1805

Here is the main parts photo of the Vertical style VC 1250x3200 CNC V Grooving Machine

APPLICATION

Photo taken in our customer’s workshop

Four: Machine delivery time

The machine is our standard machine, and it is in stock, we can ship the machine immediately .

Rongwin has specialized in metal working machinery and spare parts for 12 years
