Rongwin has specialized in metal working machinery and spare parts for 12 years

Home  >  Customized Product  >  Best Fiber Laser Cutting Machine Wholesale  >

cutting best laser cutting machine series for sheet metal working Rongwin

cutting best laser cutting machine series for sheet metal working Rongwin
best laser cutting machine is superior in quality.
RWL-3015 Closed type
L/C, T/T

Add success, do you want to check your shopping cart?

Product Details
With the dedication to pursue excellence, Rongwin strives for perfection in every detail.Well-chosen in material, fine in workmanship, excellent in quality and favorable in price, Rongwin's hydraulic metal shear manufacturers is highly competitive in the domestic and foreign markets.
Product Comparison
Rongwin pays great attention to integrity and business reputation. We strictly control the quality and production cost in the production. All these guarantee fiber laser cutting machine to be quality-reliable and price-favorable.After being improved greatly, Rongwin's fiber laser cutting machine is more advantageous in the following aspects.
Company Advantages
1. best laser cutting machine is superior in quality.
2. best laser cutting machine is characterized by high performance and extreme durability.
3. This product can meet the challenge of the market competition.

Company Features
1. As a pioneer in the best laser cutting machine China field, Nanjing Rongwin Machinery Technology Co.,Ltd. is steadily expanding into a broader overseas market.
2. Our research and development team has been working for years in this industry. They possess deep and insightful knowledge of the product market trends and unique understanding of product development. We believe these characteristics help us achieve the broadening the product range and achieve excellency.
3. 2000w laser cutting machine is our eternal service creed. Contact! With its cardinal tenet of 1000w laser cutting machine , Nanjing Rongwin Machinery Technology Co.,Ltd. provides all-round premium services for its costumers. Contact! affordable laser cutting machine is the management tenet from the very beginning for Nanjing Rongwin Machinery Technology Co.,Ltd.. Contact!


RWL-3015 Closed type

Working Table


Fiber Laser


1)3300W China Raycus laser source

2)3000W IPG laser source

Cutting Head

Auto Focus Raytool Cutting head

Lathe Bed

Made by our factory

X/Y axis Reducer

Taiwan APEX P2 flanged joint

X/Y axis Rack and Pinion

1 set YYC FROM Taiwan grinding din6 precision

Automatic Lubrication System


Proportional Valve

SMC from Japan,or PARKER from USA

Focus Lens


Drive Mode

Dual Drive

Electrical Control System

Siemens ,Schneider ,etc

Ball Screw and Guide Rail

1 set Ball Screw H grade precision HIWIN from TAIWAN for Z axis,  Each 2 sets H grade precision Linear Guide HIWIN from TAIWAN for both X and Y axis

Servo Motor and Drive

4 set of YASKAWA from JAPAN

Cutting thickness (in the required cutting condition)

Upto 20mm thickness M.S---3000W/3300W Cutting speed 0.6-065m/min for 20mm thickness

Water Chiller

Hanli,China famous brand

CNC and software

Cypcut from SHANGHAI

Format Supported


Power requirement

3 Phase ,50HZ, Customized Voltage

Gross Weight

Siemens ,Schneider ,etc

Packing Size






Protection mirror



Laser head nozzle

10 PCS







Protection mirror (300 hours life)

10 PCS


Laser head nozzle (800 hours life)

10 PCS


Ceramic O-ring (3000 hours life)



*The main frame adopts a gantry structure welded with all steel plate to guarantee long-term existence deformation.

*Machine bed is overall structure ,it is stable because of we do heat treatment

*The machine bed is milled by imported gantry milling in one time

*Adopting gantry rack double guide,double servo drive structure

*Improve the stability and rigidity of Y axis beam,to ensure the higher precision and higher dynamic performance of the beam movement.

*The high speed and smooth running of the shaft beam can reduce gas consumption.

The beam sliding table adopts integral casting aluminum parts, which can reduce the weight of the beam and ensure good stability, So that can meet the high-speed operation of the machine .

Water chiller

*Adopt domestic first-class brand, professional laser chiller, good stability, high precision

* With two-way temperature control, different temperature control can be performed on the laser and cutting head to ensure more stable laser and cutting head

*Functions include: water pressure alarm, high and low temperature alarm, voltage alarm, and various fault alarms.

*Use Original Germany precitec laser cutting head of top Germany Technology, Full sealed design , ensure long lifetime of mirrors.

* Laser beam is delivered to cutting head by original optical fiber cable

*Fiber cable is fixed to cutting head via QBH plug , realize easy plug in pull out of fiber cable .

*Laser beam goes through collimation lens to be aligned and achieve a better laser beam shape and quality

*Laser beam finds its focus via focusing lens unit.

* Protection lens prevents focus lens from cutting sprays and particle during cutting process.

*Height adjustment is a sensor unit inside cutting head , it can adjust height of laser cutting head automatically with high sense precision. It assists to achieve better cutting quality.

*Ceramic ring protects cutting head .

China famous brand Raycus laser source

*High beam quality output

* High reliability, long service life

*Can use air cutting to save costs

*High electro-optical conversion efficiency

* Compact design

*Optical output comes with a collimation output

*external computer control interface

Automatic lubrication system

Automatic lubrication system for Liner guide and Rack and pinion.which can easily lubricate smoothly and automatically, so that can ensure flexibility and stably of transmission system . Free maintenance and extend the lifetime of working tables.

SMC Proportional Valve

* It can automatically control 3 types of gas (O2,N2,compressor air)

*By this auto pressure control of cutting gas , it can easily and precisely control the cutting gas for different cutting shapes ,greatly improve the cutting precision of small hole ,short line… such small parts.

CYPCUT Control Software

*Nesting software optimized cutting path (read CAD drawing directly)

*Intuitive interface, perfect match with Auto CAD software.

*Software and height adjustment system communicate via net cable

*Flying cutting & Real-time power adjustment

*Cutting parameters material library

*PLC programming process

*Online troubleshooting recording

*Operational status recording

*Automatic boundary location function

*The use of closed control design: a good closed effect guarantees the control of the appliance's dust-free effect, providing protection for long hours of work.

*Configuration thermostatic air conditioning: to ensure constant temperature inside the control cabinet, to prevent the temperature changes caused by condensation in the control cabinet laser and electrical components.

*Waterproof design: The control cabinet is designed with 2 layers. There are no electrical appliances on the ground floor to deal with sudden flooding.


Japan FUJI /YASAKAWA brand servo motor                              Servo &Reducer Motor                                         Japan SHIMPO brand reducer motor

Auto Exhausting Design


We have divided into several separate rooms for dust exhausting , which save power consumption effectively.

These are available brand for our components :
